Mosites Butterfly Valve Indentification Numbers
EXAMPLE: 1 020 – 1 03 – 1 1 1
| (1) | (020) | (1) | (03) | (1) | (1) | (1) |
|---|---|---|---|---|---|---|
| TYPE | SIZE | BODY | LINER | C10/C30 INSERT A20 DISC | SHAFT | OPERATOR |
| 1 C10 | 020 2″ | 1 CS Wafer | 01 Buna-N | 1 CS | 1 CS (C10 Only) | 0 None |
| 2 A20 | 030 3″ | 2 CS Lug | 02- | 2 316 SS | 2 17-4PH SS SQ | 1 Handlever |
| 3 C30 | 040 4″ | 3 CS Narrow Wafer | 03 CPE | 3 Alloy 20 | 3 CS DBL D | 2 Gear Operator |
| 4 Full Face Envelope Gasket | 060 6″ | 4 CS Narrow Lug | 04- | 4 Hastalloy C | 4 SS DBL D 17-4PH | 3 Actuated |
| 5 Spacer | 080 8″ | 5 Aluminum Wafer | 05 EPDM | 5 Monel | 5 Alloy DBL D | |
| 6 Full Face Reinforcing Ring | 100 10″ | 6 SS Wafer | 06- | 6 Alum Bronze | 6 Monel K-500 | |
| 7 Gear | 120 12″ | 7 SS Lug | 07 Urethane | 7 Hastalloy | ||
| 8 Envelope Gasket | 140 14″ | 8 Drill Thru Lug | 08 Natural | 8 17-4 PH SS Short | ||
| 9 Accessories | 160 16″ | 09 Neoprene | 9 Alloy DBL D Short | |||
| 91 Remanufactured C10 | 180 18″ | 10 RoyalTherm (SEP) | ||||
| 92 Remanufactured A20 | 200 20″ | 11 Viton | ||||
| 93 Remanufactured C30 | 240 24″ | 12 Viton Food Grade | ||||
| 300 30″ | 13 Buna-N Food Grade | |||||
| 360 36″ | 14 Neoprene Food Grade 15 TBR |
